مشخصات سخت افزاری
|
1/3- 1.3 Megapixel Progressive CMOS Sensor
90ft IR Illumination Distance
Minimum illumination
0.2Lux Color mode
0.1Lux Black and White mode
0Lux Black and White mode with IR LED on
Automatic Infrared-Cut Filter module for night viewing
10x digital zoom
2.8mm F2.0 fixed focal length lens
Aperture F2.0
Angle of view
96° horizontal
54° vertical
108° diagonal
Minimum object distance: 8
|
|
بدنه دوربین
|
IP66 compliant weatherproof housing
|
|
ویژگی های تصویر
|
Configurable image size, quality, frame rate, and bit rate
Time stamp and text overlays
Configurable motion detection windows
Configurable privacy mask zones
Configurable exposure time, brightness, saturation, contrast, contrast, sharpness, digital WDR and 3D filter
|
|
فرمت فشرده سازی ویدیو
|
Simultaneous H.264/MJPEG format compression
H.264 multicast streaming
JPEG for still images
|
|
رزولوشن ویدیو
|
16:9- 1280x 720, 800 x 448, 640 x 360, 480 x 272, 320 x 176 up to 30 fps
4:3 – 960x 720, 800 x 592, 640 x 480, 480 x 352, 320 x 240 up to 30 fps
|
|
رابط کاربری
|
(10/100BASE-TX Ethernet port with PoE (802.3af
Optional 12VDC input jack
|
|
پروتکل های شبکه
|
IPv6
IPv4
ARP
TCP/IP
UDP
ICMP
DHCP client
NTP client (D-Link)
DNS client
DDNS client (D-Link)
SMTP client
FTP client
HTTP / HTTPS
Samba client
PPPoE
UPnP port forwarding
RTP / RTSP/ RTCP
IP filtering
QoS/DSCP
CoS
Multicast
ONVIF compliant
|
|
امنیت
|
Administrator and user group protection
Password authentication
HTTP and RTSP digest encryption
|
|
مدیریت
|
Motion detection
Event notification and uploading of snapshots/video clips via e-mail or FTP
Supports multiple SMTP and FTP servers
Multiple event notifications
Multiple recording methods for easy backup
|
|
مدیریت از راه دور
|
Take snapshots/video clips and save to local hard drive or NAS via web browser
Configuration interface accessible via web browser
|
|
ویژگی های نرم افزار D-viewCam
|
Remote management/control of up to 32 cameras
Supports all management functions provided in web interface
Viewing of up to 32 cameras on one screen
Scheduled motion triggered, or manual recording options
|
|
وزن
|
445 گرم
|
|
ویژگی های PoE
|
(PoE (802.3af
12V DC 1.5 A
|
|
گواهینامه
|
CE
CE LVD
FCC
C-Tick
|
|
نوع
|
Bullet
|
|
محل نصب
|
Outdoor
|
|
برند
|
D-link
|
