| مشخصات سخت افزاری | 1.4Megapixel progressive CMOS sensor
8meter IR illumination distance
Minimum illumination 0 lux with IR LED on
Built-in Infrared-Cut Removable (ICR) Filter module
Focal length 3.6 mm
Minimum object distance: 200 mm
Aperture: F2.0
Exposure Time: 1/7.5 sec. to 1/10,000 sec.
:Angle of view
H) 57°)
V) 34°)
D) 66°)
Built-in microphone and speaker |
|---|
| مشخصات تصویر | Configurable image size, quality, frame rate, and bit
rate
Time stamp and text overlays
onfigurable motion detection windows
Configurable shutter speed, brightness, saturation,
contrast, mirror, flip |
|---|
| فرمت ویدیو | H.264/MJPEG format simultaneous compression
H.264 multicast streaming
JPEG for still images |
|---|
| رزولوشن ویدیو | 16:9
1280x 720, 800 x 448, 640 x 360, 480 x 272, 320 x 176
(Others (supports frame rates up to 30 fps
960x 720, 800 x 592, 640 x 480, 480 x 352, 320 x 240 |
|---|
| Pan/Tilt/Zoom | Pan Range: -170° to 170°
Tilt Range: -20° to 100°
Digital Zoom: 10x
Manual Pan Speed: 5-80 ° per second
Manual Tilt Speed: 5-80 ° per second
Position Presets: 32 points |
|---|
| فرمت صدا | G.711
AAC |
|---|
| رابط کاربری | IEEE 802.11n
10/100BASE-TX Fast Ethernet
microSD/SDHC card slot
Single audio input/output port
DI/DO Port |
|---|
| پروتکل های شبکه | IPv6, IPv4, TCP/IP, UDP, ICMP
DHCP client
(NTP client (D-Link
DNS client
(DDNS client (D-Link
SMTP client
FTP client
HTTP / HTTPS
Samba client
PPPoE
UPnP port forwarding
RTP / RTSP / RTCP
IP filtering
QoS / CoS
Multicast
ONVIF compliant
Bonjour
SNMP |
|---|
| امنیت | Administrator and user group protection
Password authentication
HTTP and RTSP authentication |
|---|
| Event Management | Motion detection
Event notification and uploading of snapshots/video clips via e-mail or FTP
Sound level detection
Scheduled recording |
|---|
| ارتباط بی سیم | Non Wi-Fi, Wi-Fi |
|---|
| نوع دوربین | Indoor |
|---|
| PoE | Non PoE |
|---|
| برند | D-link |
|---|
