مشخصات سخت افزاری
|
1/4”1Megapixel progressive CMOS sensor
5meter IR illumination distance
: Minimum illumination
Color (Day Mode), IR LEDs off: 2.6 lux
B/W (Night Mode), IR LEDs off: 1.5 lux
B/W (Night Mode), IR LEDs on: 0 lux
Built-in Infrared-Cut Removable (ICR) Filter module
Fixed length 2.45 mm
Aperture F2.4
: Angle of view
H) 112°)
V) 77°)
D) 120°)
Minimum object distance: 50 cm
Built-in microphone
|
|
مشخصات تصویر
|
Configurable image size, quality, frame rate and bit rate
Time stamp and text overlays
Configurable motion detection windows
Configurable shutter speed, brightness, saturation, contrast, and
sharpness
|
|
فرمت ویدیو
|
Simultaneous H.264/MPEG-4/MJPEG multi-format compression
JPEG for still images
|
|
رزولوشن ویدیو
|
720P (1280 x 720), VGA (640 x 352), QVGA (320 x 176) at
up to 30 fps
|
|
فرمت صدا
|
PCM
ADPCM
|
|
رابط کاربری
|
802.11n/g wireless with WPA/WPA2 encryption
Operates on 2.4 GHz band
microSD card slot
Single-band 1T1R mode supports a maximum data
rate of 72.2 Mbps (PHY rate) using 20 MHz bandwidth
|
|
پروتکل های شبکه
|
IPv6, IPv4, TCP/IP, UDP, ICMP
DHCP client
(NTP client (D-Link
DNS client
(DDNS client (D-Link
SMTP client
FTP client
HTTP / HTTPS
Samba client
PPPoE
UPnP port forwarding
RTP / RTSP / RTCP
IP filtering
QoS / CoS
Multicast
ONVIF compliant
Bonjour
SNMP
|
|
امنیت
|
Administrator and user group protection
Password authentication
HTTP and RTSP authentication
|
|
Event Management
|
Motion detection
Event notification and uploading of snapshots/video clips via e-mail or FTP
Sound level detection
|
|
منبع تغذیه
|
5V DC, 1.2 A through external power adapter
Power adapter: 100 to 240 V AC, 50/60 Hz
|
|
ارتباط بی سیم
|
Non Wi-Fi
,
Wi-Fi
|
|
نوع دوربین
|
Outdoor
|
|
PoE
|
Non PoE
|
|
برند
|
D-link
|
