استانداردهای ADSL
|
Full-rate ANSI T1.413 Issue 2
ITU-T G.992.1 (G.dmt) Annex A
ITU-T G.992.2 (G.lite) Annex A
(ITU-T G.994.1 (G.hs
|
|
استانداردهای ADSL2
|
ITU-T G.992.5 Annex A/M
|
|
پروتکل ATM/PPP
|
Multiple protocol encapsulation over AAL5
Bridged and routed Ethernet encapsulation
Logical Link Control (LLC) encapsulation
VC-based multiplexing
RFC 1483, RFC 2684
MAC Encapsulated Routing RFC 1483 MER
ATM Forum UNI3.1/4.0 PVC Up to 8 PVCs
Multiple services, PPPoE, bridge, MER over single PVC: optional
ATM Cell Format ITU-T Rec. I.361
(ATM Adaptation Layer Type 5 (AAL5)
ITU-T I.610 OAM Principles & Functions
include F4/F5 loopback
ATM QoS (Traffic Shaping) UBR, CBR,
rt-VBR, nrt-VBR
PPP over ATM RFC 2364
PPP over Ethernet RFC 2516
PPP Link Control Protocol (LCP) RFC 1661
Internet Protocol Control Protocol (IPCP) RFC 1332
PPP Authentication Protocol (PAP) RFC 1334
PPP Challenge Handshake Authentication Protocol (CHAP) RFC
1994
Microsoft PPP CHAP extensions RFC 2433
|
|
پروتکل های شبکه
|
Ethernet to ADSL Self-Learning
Transparent Bridging
Internet Control Message Protocol (ICMP) RFC 792
IP Static Routing
Routing Information Protocol (RIP, RIPv2) RFC 1058, RFC 1723
Network Address Translation (NAT) RFC 1631
Virtual Server, Port Forwarding
NAT ALGs (optional): MSN/AOL/Yahoo
Messenger, FTP, SNMP, CUSEEME, Real
Audio, MIRC, SIP, ICQ, games
DHCP server/client/relay RFC 2131
DNS Relay, DDNS
IGMP proxy v.3 supported
(Simple Network Time Protocol (SNTP
|
|
فابروال
|
NAT firewall
MAC Filtering
Packet Filtering IP/ICMP/TCP/UDP
(URL Content Filtering (keyword filtering
Domain Blocking
(Stateful Packet Inspection (SPI
(Denial of Service prevention (DoS
Intrusion Detection
System/Log
User Authentication PAP RFC 1334
User Authentication CHAP RFC 1994
DMZ
|
|
پشتیبانی از VPN
|
IPSec/PPTP/L2TP pass-through
|
|
سرویس کیفیت خدمات
|
Traffic Prioritization/Classification
Port-based priority
(802.1p (8 queues
Diffserv TOS
Application port-based priority
User-defined priority (TCP/UDP/ICMP
4 priority queues per PVC
|
|
نشانگر LED
|
Power
Status
DSL Link/Activity
Ethernet Link/Activity
|
|
منبع تغذیه
|
5VDC/1.2A switching power adapter or
9VAC/1A linear power adapter
(Dying Gasp (optional
|
|
تکنولوژی Wi-Fi
|
ندارد
|
|
استاندارد DSL
|
ADSL2+
|
|
درگاه USB
|
USB 1.1
|
|
برند
|
D-link
|
مهسا –
Vpn و پورت فورواردينگ هم داره چجوری ست کنم؟
مدیر فروش heshmati@avang.ir –
با سلام
این دستگاه از Port Forwarding پشتیبانی میکند، ولی امکان ست کردن VPN وحود تدارد و تنها به صورت VPN Pass-through میباشد.
جهت یادگیری تنظیمات فنی این دستگاه میتوانید دفترچه راهنمای این محصول را مطالعه بفرمایید :
دانلود
حامد –
درود.
این مدل مودم برای خرید موجود هست؟
چه فروشگاهی داره و قیمت؟
مدیر فروش ادمین آونگ –
سلام. ما فروش مستقیم نداریم. میتونید از فروشکاه های آنلاین خریداری کنید
