| رابط های کاربری | 44 پورت 10/100/1000Mbps
4 پورت combo 10/100/1000BASE-T/SFP |
|---|
| استانداردها و قابلیت های پورت | (IEEE 802.3 10BASE-T Ethernet (twisted-pair copper
(IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper
(IEEE 802.3ab 1000BASE-T Gigabit Ethernet (twisted- pair copper
Auto-negotiation
IEEE 802.3x Flow Control |
|---|
| Full/Half-Duplex | Full/half duplex for 10/100Mbps speeds
Full duplex for Gigabit speed |
|---|
| ظرفیت سوییچ | 71.4Gbps |
|---|
| Transmission Method | Store-and-forward |
|---|
| جدول MAC Address | 8K |
|---|
| MAC Address Update | Up to 256 static MAC entries
Enable/disable auto-learning of MAC addresses |
|---|
| Maximum 64 bytespacket forwarding rate | 35.7Mpps |
|---|
| RAM Buffer | 1MB |
|---|
| منبع تغذیه | 100to 240 VAC 50/60 internal universal power supply |
|---|
| Maximum PowerConsumption | 59.1W |
|---|
| Heat Dissipation | 201.65BTU/hr |
|---|
| ابعاد | 440mm x 210mm x 44mm
19inch standard rack mounting width
1U height |
|---|
| وزن | 4.04kg |
|---|
| MTBF | 322,402hours |
|---|
| نشانگر LED | ( Power (per device
Link/Activity/Speed
(per 10/100/1000 Mbps port)
(Link/Activity/Speed (per SFP port |
|---|
| EMI | FCC Class A
CE Class A
ICES-003
VCCI Class A
C-Tick
BSMI |
|---|
| Safety | cUL, LVD |
|---|
| ویژگی های لایه 2 ای | IGMP Snooping
IGMP v1/v2 Snooping-
Supports 256 IGMP groups-
Supports at least 64 static multicast addresses-
IGMP per VLAN-
Supports IGMP Snooping Querier-
Spanning Tree Protocol
802.1D STP-
802.1w RSTP-
Loopback Detection
802.3ad Link Aggregation
Max. 10 groups per device/8 ports per group-
Port Mirroring
Multicast Filtering
LLDP, LLDP-MED |
|---|
| VLAN | 802.1Q
VLAN Group
Max. 256 static VLAN groups-
Max. 4094 VIDs-
Management VLAN
Asymmetric VLAN
Auto Voice VLAN
Max. 10 user-defined OUI-
Max. 8 default OUI-
Auto Surveillance VLAN |
|---|
| QoS | 802.1p Quality of Service
4 queues per port
Queue Handling
Strict-
(Weighted Round Robin (WRR-
CoS based on
802.1p Priority Queues-
DSCP-
ToS1-
Bandwidth Control
(Port-based (Ingress/Egress, min. granularity for 10/100/1000Base-T ports is is 64 Kb/s-
Configurable MDI/MDIX
SNMP
Supports v1, v2, v3-
SNMP Trap
System Log
Max. 500 log entries-
BootP/DHCP Client |
|---|
| AAA | 802.1X Port-based Authentication
Supports RADIUS Server-
Supports EAP, OTP, TLS, TTLS, PEAP-
OAM
Cable Diagnostics
Factory Reset |
|---|
| محل استفاده | Rackmount |
|---|
| تعداد پورت | 48 پورت و بالاتر |
|---|
| PoE | None PoE |
|---|
| نوع پورت | Gigabit Ethernet |
|---|
| نوع پورت آپلینک | Copper/Gigabit Fiber combo, Gigabit Ethernet, Gigabit Fiber |
|---|
| برند | D-link |
|---|
