| مشخصات سخت افزاری | 1/4”1Megapixel progressive CMOS sensor
Minimum illumination:1.0 lux
fixed length: 3.45 mm
Aperture: F2.0
Minimum object distance 20 inches
:Angle of view
H) 57.8°)
V) 37.8°)
D) 66°) |
|---|
| مشخصات تصویر | Configurable image size, quality, frame rate and bit rate
Time stamp and text overlays
Configurable motion detection windows
configurable privacy mask zones
Configurable shutter speed, brightness, saturation, contrast, and
sharpness |
|---|
| فرمت ویدیو | Simultaneous H.264/MPEG-4/MJPEG multi-format compression
JPEG for still images
H.264/MPEG-4 multicast streaming |
|---|
| رزولوشن ویدیو | 16:9
1280x 720, 800 x 450, 640 x 360 up to 30 fps
4:3
1024x 768, 800 x 600, 640 x 480 up to 30 fps |
|---|
| فرمت صدا | G.726 |
|---|
| رابط کاربری | 1DI / 1 DO
Micro SD card slot
Built-in microphone
3.5mm audio output jack |
|---|
| پروتکل های شبکه | IPv6, IPv4, TCP/IP, UDP, ICMP
DHCP client
(NTP client (D-Link
DNS client
(DDNS client (D-Link
SMTP client
FTP client
HTTP / HTTPS
Samba client
PPPoE
UPnP port forwarding
RTP / RTSP / RTCP
IP filtering
QoS / CoS
Multicast
ONVIF compliant
Bonjour
SNMP |
|---|
| امنیت | Administrator and user group protection
Password authentication
HTTP and RTSP authentication |
|---|
| درگاه micro SD | Supports microSD/SDHC/SDXC
Up to 128 GB |
|---|
| mydlink Camera Recorder | Supports 2 external USB hard drives up to 4 TB each
Records up to 4 D-Link Wi-Fi Cameras
DNR-202L and USB hard drives sold separately |
|---|
| Event Management | Motion detection
Event notification and uploading of snapshots/video clips via e-mail or FTP
Supports multiple SMTP and FTP servers
Multiple event notifications
Multiple recording methods for easy backup |
|---|
| مدیریت از راه دور | Take snapshots/video clips and save to local hard drive or NAS via web browser
Configuration interface accessible via web browser |
|---|
| منبع تغذیه | 5V DC 1.2 A, 50/60 Hz |
|---|
| پشتیبانی از سیستم عامل های | Windows 7/Vista/XP system, Pocket PC, or mobile phone with 3GPP playback support |
|---|
| قابلیت های نرم افزار D-ViewCam™ | Remote management/control of up to 32 cameras
Viewing of up to 32 cameras on one screen
Supports all management functions provided in web interface
Scheduled motion triggered, or manual recording options |
|---|
| ارتباط بی سیم | Wi-Fi |
|---|
| نوع دوربین | Indoor |
|---|
| PoE | Non PoE |
|---|
| برند | D-link |
|---|
